This tutorial will walk you through setting up Multi-Node and writing your first smart contract in Graphene blockchain. This is a straightforward, step by step tutorial on Graphene smart contracts that picks off from our previous tutorial on basics of Graphene.

Address generation

We’ll start off with address generation.

1. Open terminal. Enter the following:

programs/witness_node/witness_node --rpc-endpoint #Runs the node without any configuration
programs/cli_wallet/cli_wallet #Run cli_wallet with any configuration in new terminal, keep the node open

2. In cli_wallet terminal, enter the following:

set_password tadas
unlock tada
  • Run these command four or more times and save the json for the pub/priv key pairs.

Setting up private testnet nodes

We’ll now set up private testnet nodes.

1. Delete object_database, witness_node_data_dir, wallet.json directory and files from graphene folder.

2. Open a new terminal instance. Enter the following:

mkdir -p genesis
programs/witness_node/witness_node --create-genesis-json genesis/my-genesis.json

3. Open my-genesis.json and modify the contents as follows:

(github plugin – doc my-genesis.json)

  • Our example will be using only three initial accounts, so delete the others.
  • Change witness candidates to three witnesses.
  • Assign different public addresses and block_signing to witness candidates that you generated in the steps above.

Let’s start setting up different nodes

1. Open a new instance of terminal. Enter the following:

mkdir data
cd data

2. Make three folders named blockprod-1/2/3 and put the following config.ini files inside all three of them (github plugin doc – config.ini)

3. Change the parameters of config.ini files as below

  • Change the p2p-endpoint = <ip_address>:<free_port>
  • Alter the genesis-json = genesis/my-genesis.json
  • Change the private-key = [pub/priv generated], three similar arrays.
  • Open rpc-endpoint to any port.

4. Open a new instance of terminal. Enter the following:

programs/witness_node/witness_node --data-dir data/blockprod-1 (in one terminal)

5. Use the following set of commands in a new terminal to generate Witness account.

programs/cli_wallet/cli_wallet (in new terminal)
set_password tadas
unlock tadas
import_key "nathan" 5KQwrPbwdL6PhXujxW37FSSQZ1JiwsST4cqQzDeyXtP79zkvFD3
import_balance nathan [5KQwrPbwdL6PhXujxW37FSSQZ1JiwsST4cqQzDeyXtP79zkvFD3] true
upgrade_account nathan true
suggest_brain_key (save the json- mnemonic, wif-priv, pub in a .txt file).
create_account_with_brain_key "Here will be the brain key you just copied in above command" my-account nathan nathan true.
transfer nathan my-account 10000 CORE "have some CORE" true.
upgrade_account my-account true
create_witness my-account "" true
vote_for_witness my-account my-account true true
vote_for_witness nathan my-account true true

6. Now add the pub/priv key pair (calculated in above step) in data/my-blockprod2/config.ini inside private-key field and add witness-id = 1.6.4.

7. Run the second node in another terminal

programs/witness_node/witness_node --data-dir data/blockprod-2
Finally, we’ll be writing our first smart contract on graphene blockchain.

This smart contract will simply store user data and fetch it in cli-wallet.

Writing first smart contract on Graphene blockchain

1. Firstly, we will add operation to store user so for that we have to register an operation named “create_user_operation” in libraries/app/impacted.cpp file.

2. Secondly, we will make the user_object.hpp file in which we declare all the fields and type which will be stored in user profile libraries/chain/include/graphene/chain/user_object.hpp

3. Thirdly, we will declare a method to insert data in db in form of transaction in file libraries/chain/include/graphene/chain/user_evaluator.hpp

4. Define the methods do_evaluate and do_apply for inserting values of user in db in libraries/chain/user_evaluator.cpp

5. Following this, we will make a method for this operation to set its fees parameter and take arguments in libraries/chain/include/graphene/chain/protocol/user.hpp

6. Now, we have to add our operation name in operations file under libraries/chain/include/graphene/chain/protocol/operations.hpp

Add header file in operations.hpp

Then add the operation name under typedef fc::static_variant<

7. Add the user_object type in libraries/chain/include/graphene/chain/protocol/types.hpp

Make changes as listed below

  • Include impl_user_object_type as the new value to the enum impl_object_type
  • Declare the class class user_object
  • Create a typedef
typedef object_id<implementation_ids, impl_user_object_type, user_object>                          user_id_type;
  • Pass it to the FC_RELECT macro
FC_REFLECT_TYPENAME( graphene::chain::user_id_type )

8. We have to add the evaluator in libraries/chain/db_init.cpp file and register our user_index

9.  Add the user protocol in libraries/chain/CMakeLists.txt

10. Now add a get method in database.hpp libraries/chain/include/graphene/chain/database.hpp
Add the header file for user_object and then add then declare the method for getting the user

#include <graphene/chain/user_object.hpp>
const user_object &get_user(account_id_type account) const;

11. Define method in db_getter.cpp in libraries/chain/db_getter.cpp

12. Now expose an api to fetch user in database_api.hpp. Include the header file of user object and add the below method inside database_api class

 optional<user_object> get_user(account_id_type from) const;

And export the function inside FC_API(graphene::app::database_api, as


Finally, define the exposed function in database_api.cpp file as
* inside database_api_impl

    optional<user_object> get_user(account_id_type from) const;

graphene blockchain 2

Congratulations! You’ve reached the end of this tutorial and know how to write smart contracts on Graphene. Now you can revisit our previous tutorial on Graphene blockchain to brush up the concepts again, or have a look at other tutorials. For more information, and to get your business up on Graphene smart contracts, contact us.
